BIGTREETECH EZ2209 Stepper Driver

BIGTREETECH EZ2209 Stepper Driver

The EZ2209 is a pluggable stepper motor driver module designed by Bigtreetech with excellent performance, convenient plugging and unplugging, simply beautiful and practical.

Features

• StealthChop can realize quieter operation of the motor when running at low speed. It is recommended to select it when the maximum speed of the motor is lower than 300RPM
• SpreadCycle can achieve quietness and low power consumption in a wide range of speed and torque. It is recommended to select it when the maximum speed of the motor exceeds 300RPM
• StallGuard2™: It can be used for motor stall detection when there is no limit switch (limit switch is recommended)
• The newly developed board frame is used to match the new connector, so that customers can experience the easy plug’n’play compared to the traditional drivers with pins
• Adopt a new type of customized heat sink to enhance the heat dissipation capacity while protecting the driver chip from external damage

Technical Data:

• Driver Chip: TMC2209-LA
• Supported Voltage: 12-24V
• Max Current: 2A
• Recommended Current: <= 1.3A
• Operation mode: UART Mode
• Sensing Resistance: 0.11R
• Stealth Chop Mode
• Spread Cycle
• Stall Guard
• Max. Subdivision: 256
• Size: 18.5×19.8mm

More info: on GIT
