LDO-35STH52-1504AH Stepper Motor

Datasheet daLDO-35STH52-1504AH Stepper Motor

LDO 1.8° High temperature linear stepper motor (180°C). Stepper motor for Voron 0.1 & 0.2 A/B axis (has been changed from the LDO-35STH48-1684AH).

Specifications:

• NEMA 14
• 1.8° Step Angle
• 200 Steps Per Revolution
• 1.5 Amp
• 0.37 Nm Holding Torque
• 52mm Body
• 22mm Output Shaft (5mm diameter) (15mm D-Shaped)

Datasheet:

LDO-35STH52-1504AHVRN_RevA-technical-datasheet
